1.3 APP Service Power Supply Features, continued
Output Voltage Selector
The VAC switch is used to select the desired output voltage. Output options
are 60, 75 and 90 Volts.
NOTE: Verify that output voltage settings are correct before operating
power supply. Do not rotate switch when unit is in operation.
Always remove power from unit when selecting output settings.
60/ 75/ 90 VAC Output Connector
The 60/ 75/ 90 VAC output connector supplies up to 22 Amps of power to a
Service Power Inserter (SPI) through an output cable.
Output Cables
9015S:
Included with the APP 9015S is an output cable used to connect the Service
Power Supply to the SPI, via a four-pin Jones connector.
9022S:
Included with the APP 9022S are two 6-ft output "Y" cables. One cable
terminates with two Jones connectors, and provides service power to one or
two separate 20A SPIs. The other cable terminates with two 25A connectors,
for 25A SPIs.
Input Connector
Input Connector is used to connect the APP SPS to line power through an AC
line cord. The cord plugs directly into enclosure convenience outlet.
The APP 9022S includes two power cords: One with a 5-20P plug to set
voltage to 120 VAC; and one with a 6-15P plug to set voltage to 240 VAC.
9022s Option: 30-Ft Output Cables
A 30-foot output kit is available. This kit provides "Y" cables for both 25A and
Jones connectors. Alpha part number: 745-094-20.
For use with a twist lock receptacle, this line cord is equipped with a NEMA
L5-30P plug. Alpha part number: 874-935-22.
9022S Option: 10-Ft Cord w/30A Connector and Twist Lock Plug (125VAC)
