Alpha Technologies UPE-M Series User Manual
Page 25
25
031-145-C0-002 Rev. B
3.0
Installation, continued
3.4
Battery Installation, continued
Tools Needed:
Two 7/16” open end wrenches
Procedure:
This section is for reference only, follow instructions included in the battery cable kit. This procedure
covers the UPE-M3 (one tray), and the UPE-M6 and UPE-M8 (two trays).
1.
Release the latch on the left slide. Pull the (lower) tray out until it reaches the stops.
2.
Install three or four batteries as shown in Fig. 3-11 (following page). Wire in accordance with
the diagram included in the Battery Cable Kit.
3.
Disengage the hold-open latch and slide the battery tray into the enclosure.
4.
Repeat for the center tray (UPE-M6 and UPE-M8 only).
