3-4
3. Installation
031-093-C0-001 © 3/99
3. Slide the CE-G enclosure away from the CE-X enclosure.
4. Drill with a 1/4” hole through the wall of the CE-X enclosure where
previously marked.
NOTE: Before drilling through the CE-X cabinet wall,
ensure that the area behind the wall is clear
of any wires, gas hoses, or pipes.
5. With the anchor bolt pattern marked, drill holes for the installation of
anchor studs.
Tools required:
Stainless steel wedge-type stud anchor , 3/8" dia., 3-3/4" in length (4).
4 each, 3/8” flat washer, 3/8” lock washer, and hex nut.
Hand Drill or Rotary Hammer
3/8” Concrete or Masonry bit(s)
Hammer
Mounting bolt installation procedure:
1. At the points located in step 3 above, drill holes for the anchor studs.
Each hole should be at least 1-3/4” deep to properly secure the
enclosure to the pad.
2. With the hammer, tap the anchor studs into their respective holes.
3. Brush away any debris from the drilling prior to proceeding.
3.3 Installation Procedure, continued
