Page 13: 0 introduction, continued 1.3 capacity, continued
13
745-680-C5-002, Rev. A
Amps
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
162.6
106.4
80.5
65.3
38
27.1
21.2
17.4
11.4
9.3
4.9
1.80
174.7
112.1
84.2
67.9
39.2
27.9
21.8
17.9
11.8
9.6
5.1
1.75
185.6
117.2
87.3
70.2
40.3
28.6
22.3
18.4
12.1
9.9
5.2
1.70
194.9
121.3
89.9
72
41.1
29.2
22.7
18.7
12.3
10
5.3
Power (Watts)
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
312.2
206
156.9
127.9 75.4
54.2
42.5
35.1
23.1
18.9
9.9
1.80
331
215.4
163.1
132.4 77.5
55.5
43.5
35.9
23.7
19.4
10.2
1.75
347.6
223.6
168.3
136.2 79.2
56.7
44.4
36.6
24.2
19.8
10.5
1.70
361.7
230.3
172.6
139.2 80.6
57.5
45
37.1
24.5
20.1
10.7
A/H Capacity
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
40.7
53.2
60.4
65.3
75.9
81.3
84.7
87.1
91.5
93.4
98.6
1.80
43.7
56.1
63.1
67.9
78.5
83.8
87.2
89.7
94.3
96.2
101.7
1.75
46.4
58.6
65.5
70.2
80.6
85.9
89.3
91.8
96.5
98.6
104.4
1.70
48.7
60.7
67.4
72
82.2
87.5
91
93.5
98.3
100.4
106.6
1.0
Introduction, continued
1.3
Capacity, continued
1.3.1 Ratings
3.5 HP Ratings
Amps
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
198.7
128.3
95.9
77
43.7
30.8
24
19.4
12.5
10.1
5.4
1.80
212.8
134.6
99.7
79.7
44.9
31.6
24.5
19.8
12.8
10.4
5.6
1.75
225.2
139.9
102.9
81.9
45.9
32.2
25
20.2
13.1
10.6
5.7
1.70
235.7
144.3
105.5
83.7
46.7
32.8
25.4
20.5
13.3
10.8
5.8
Power (Watts)
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
383.9
251.6
189.4
152.7 87.5
61.9
48.2
39
25.3
20.5
11
1.80
406.8
261.8
195.7
157.2 89.6
63.3
49.3
39.9
25.9
21
11.3
1.75
426.7
270.5
200.9
160.9 91.3
64.5
50.1
40.6
26.4
21.3
11.5
1.70
443.1
277.4
205.1
163.8 92.6
65.4
50.8
41.2
26.7
21.6
11.6
A/H Capacity
End Voltage
15min
30min
45min 1hr
2hr
3hr
4hr
5hr
8hr
10hr
20hr
1.85
49.7
64.2
72
77
87.5
92.5
95.8
96.9
100.3
101.3
108.8
1.80
53.2
67.3
74.8
79.7
89.8
94.8
98.1
99.2
102.7
103.8
111.7
1.75
56.3
70
77.2
81.9
91.8
96.7
100
101.1 104.7
105.9
114
1.70
58.9
72.1
79.1
83.7
93.3
98.2
101.5
102.6 106.3
107.5
115.8
4.0 HP Ratings
