AEROMOTIVE Part # 17140
INSTALLATION INSTRUCTIONS
Not For Street Use!
CAUTION:
Installation of this product requires detailed knowledge of automotive systems and repair procedures. We
recommend that this installation be carried out by a qualified automotive technician.
Installation of this product requires handling of gasoline. Ensure you are working in a well ventilated area
with an approved fire extinguisher nearby. Extinguish all open flames, prohibit smoking and eliminate all sources
of ignition in the area of the vehicle before proceeding with the installation.
When installing this product, wear eye goggles and other safety apparel as needed to protect yourself
from debris and sprayed gasoline.
WARNING!
The fuel system is under pressure. Do not open the fuel system until the pressure has been relieved.
Refer to the appropriate vehicle service manual for the procedure and precautions for relieving the fuel system
pressure.
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.
The enclosed Aeromotive fuel pump utilizes an o-ring sealed AN-10 style inlet and outlet ports; these ports are NOT PIPE
THREAD and utilize NO THREAD SEALANT.
A high capacity 100 micron fuel filter must be installed between the fuel tank and pump inlet as well as a high capacity 10
micron fuel filter on the pump outlet. We recommend an Aeromotive P/N 12302 on the inlet side and an Aeromotive P/N
12301 on the outlet side. Call us for info.
To use this pump in your vehicle’s fuel system, we strongly recommend the following:
Gravity feed the pump by mounting it lower than the fuel cell.
Utilize AN-10 size high pressure fuel lines, fittings and o-rings for all connections from the
fuel cell to the engine.
Failure to follow the above recommendations may result in fuel leakage, bursting of the fuel lines, poor vehicle
performance and/or decreased fuel pump life! Improper installation will void all warranties for this product!
Performance Specifications: Model 17140
Fuel Compatibility Gasoline & Methyl Alcohol
Port Sizes Inlet & Outlet AN-10
Pulley and Belt Information:
½” wide, 3/8” or “L” Pitch timing pulley and Belt
Pump speed must be ½ the engine speed.
Included Pump Pulley: 28-tooth
Recommended Crank Pulley: 14-tooth
Pump mounting:
Pump should be mounted as low as possible to ease priming.
Due to the large number of applications, no specific mounting instructions are provided.
