9. Technical data
Item number
TVCC71000 TVCC71500
TV standard
PAL
Resolution
650 TVL
Bildaufnehmer
1/3‘‘ Sony Exview HAD II CCD
DSP
Sony Effio-E
Picture elements (total)
1020(H) x 596(V)
Picture elements (effective)
976(H) x 582(V)
Signal-to-noise ratio
50 dB
Minimum illumination (day)
0.01 Lux @ F2.0
0.01 Lux @ F2.0
Minimum illumination
(night)
0 Lux @ F2.0 (external IR)
0 Lux @ F2.0
Day/night
IR cut filter removable
(ICR), Color / B/W
IR cut filter removable
(ICR), Color / B/W
Lens
2.8~10.5mm, F2.0
2.8~10.5mm, F2.0
IR LEDs
-
24 LEDs, 850nm
IR Range
-
5 / 10 / 20 m
Horizontal angle of view
101.8°~27.4° 101.8°~27.4°
Electronic Shutter
AI AI
Synchronisationi
Internal
Automatic gain control
(AGC)
28 dB (max.)
Backlight compensation
(BLC)
BLC
WDR
Max. 46 dB
Noise reduction
2D DNR
White balance
ATW, 1800K~10500K
Control options
OSD OSD
Protection class
IP66
Video signal
2 x FBAS, 1V s-s, 75 Ohm (BNC, Cinch), 5.5x2.1mm (DC)
Operating temperature
-10°C ~ +50°C
Humidity
0~85%, not condensing
Nominal supply voltage
12 VDC
Power consumption
max. 250 mA
max. 350 mA (IR off),
max. 450 mA (IR on)
Dimension (HxØ)
99.5 x 145 mm
Weight
700 g
700 g
Certifications
CE, RoHS, Reach
