32
Function Description
AREA SELECT Selects the private zone to be processed (1–16)
MODE OFF: The selected mask is deactivated.
ON: The selected mask is activated.
POSITION TOP: Distance to the upper edge of the mask
BOTTOM: Distance to the bottom edge of the mask
LEFT: Distance to the left edge of the mask
RIGHT: Distance to the right edge of the mask
COLOR Colour options for the individual zones:
white, black, red, green, blue, yellow, cyan, magenta
TRANSP Value for the optical transmittance of the colour represented
(0.0–1.0)
MOSAIC ON: Activated mosaic representation of the selected zone.
OFF: Deactivated mosaic representation of the selected zone.
DEFAULT Restores all values in the sub-menu to the factory settings
RETURN Back to main menu
EFFECT
DISPLAY
>
COLOR >
VIEW MODE LCD
POSI / NEGA POSI
MIRROR OFF
FREEZE OFF
DEFAULT
NEXT>
RETURN>
ALARM IN
ON
DEFAULT
BACK>
RETURN>
Function Description
DISPLAY ON: Activates the function
OFF: Deactivates the function
TITLE ID: Assignment of a camera title in video image A
maximum of 16 characters can be entered. Press the ENTER
button to go to the menu for setting the ID.
<>: Cursor position
CLR: Deletes the characters currently highlighted
POS>: Defines the position of the camera title
