6.2 Cleaning
Wipe the product with a clean, dry cloth. If the device is very dirty, you can moisten the cloth with
lukewarm water.
Make sure that no liquids can enter the equipment as the device can be destroyed.
Never use chemical detergents as they could attack the surface of the device
7. Disposal
Devices with this marking should not be put in the household garbage. Dispose of the
product at the end of its lifetime according to the applicable regulations.
8. Pin-Assignment
RJ45 Input
(only data)
RJ45 Output
(data and power)
PIN Symbol Description Symbol Description
1 Rx+ Data receive Rx+ Data receive
2 Rx- Data receive Rx- Data receive
3 TX+ Data transmission TX+ Data transmission
4 NC Not connected -VDC Power injection (+)
5 NC Not connected -VDC Power injection (+)
6 TX- Data transmission TX- Data transmission
7 NC Not connected -VDC Power injection (-)
8 NC Not connected -VDC Power injection (-)
Warning:
Pin 7 and 8 should not be shorted to Ground.
