15
English
6.2 Cleaning
Wipe the product with a clean, dry cloth. If the device is very dirty, you can moisten the cloth with
lukewarm water.
Make sure that no liquids can enter the equipment as the device can be destroyed.
Never use chemical detergents as they could attack the surface of the device
7. Disposal
Devices with this marking should not be put in the household garbage. Dispose of the
product at the end of its lifetime according to the applicable regulations.
8. Pin-Assignment
RJ45 Input
(data and power)
RJ45 Output
(only data)
PIN Symbol Description Symbol Description
1 Rx+ Data receive Rx+ Data receive
2 Rx- Data receive Rx- Data receive
3 TX+ Data transmission TX+ Data transmission
4 +VDC Feeding power (+) U Not connected
5 +VDC Feeding power (+) U Not connected
6 TX- Data transmission TX- Data transmission
7 -VDC Feeding power (-) U Not connected
8 -VDC Feeding power (-) U Not connected
Warning:
Pin 7 and 8 should not be shorted to Ground.
9. Technical data
Type number TVAC25010
Inputs 1x RJ-45 (PoE, data & power)
Input power Typical: -48 VDC (-42 VDC – -60 VDC)
Input power 12W @ 48 VDC
Outputs 1x RJ-45 (Data); 1x DC-OUT (5,5 x 2,1 mm)
Output voltage 12 VDC / 1A
Output power 12 W
Data rate 10/100 MB/s
Connection cable length 30 cm per Output
Operation temperature -10°C - +60°C
Operation Humidity max. 90%, RH
Dimensions (BxHxT) 86 mm x 36 mm x 76 mm
Weight 110 g
