12
English
Explanation of terms
Display information
SD Full…
Storage capacity
Once your micro SD card is full, the “SD Full” message appears every
3 seconds on your screen.
If an SD card has not been inserted “No SD” appears.
Check the storage capacity of the card regularly!
No SD…
Low Battery…
Battery life
As soon as the battery is running low, the “Low Battery” message
appears.
Check the batteries regularly!
PIR recording (Picture / Video)
Recording mode
If the “PIR recording (Picture / Video)” message appears, the camera is
recording.
Set Time Adjusting date and time.
Time-lapse Interval
Defining the time-lapse interviews.
You can choose between the following values:
1,5 seconds 5 seconds 10 seconds 30 seconds
1 minute 5 minutes 10 minutes 30 minutes
1 hour 5 hours 10 hours 24 hours
AVI Frame Rate
Here you can set the frame rate for the video recording in AVI
format.
You can choose between the following frame rates:
1FPS, 10FPS, 30FPS
Motion Record Live
Defining the recording duration for motion detection.
You can choose between 10 frames or 30 seconds.
10 images = 10 images (1 image/ second) are recorded and saved as
an AVI file.
30 seconds = a 30 second long video is saved in AVI format.
Video Resolution
Defining the resolution.
Here you can choose between the following video resolutions:
1280 x 720, 640 x 480
Settings Here the current settings of the menu items are displayed.
Band Filter
Defining the network frequency
Here you can make adjustments to the network frequency in your
country to prevent flickering in the picture.
You can choose between the following frequencies.
50Hz / 60Hz
Firmware Version
In the “Firmware Version”menu item, you can see the current version
of the firmware.
Reset Setting
Restore default parameters.
This function lets you reset the camera to the default settings and all
the previous settings are deleted.
To do so, select “Yes”, confirm with
“OK” and then “Set”.
Exit
After exiting the menu the camera returns to normal operating mode
and records again.
