N e t w o r k Ap p l i a n c e F W S - 7 8 0 0
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 Clear RTC
JP2 Clear CMOS
JP3 AT/ATX Power Type Select
JP4 Compact Flash Card Power Select
FP1 Front panel connector
Chapter 2 Quick Installation Guide 2-6
