Appendix C Standard LAN Bypass Platform Setting
C-5
PWR_ON
Use for configuring LAN Bypass function behavior to LAN kit,
when system power on.
1: Bypass
0: Pass Through
PWR_OFF
Use for configuring LAN Bypass function behavior to LAN kit,
when system power off.
1: Bypass
0: Pass Through
WDT_EN
Use for configuring WDT function behavior to LAN kit, when
WDT triggered.
0: Normal WDT reset (Default)
1: Force Bypass
ACT_EN
Use for activating programming of LAN kit. It is edge triggering
(falling edge 1 to 0) and should be set to high(1) as its normal
state.
Table 3 : LAN Bypass relative register mapping table
Attribute
Register(I/O)
BitNum
Value
LAN_ID2
R/W
0xA05
(Note1)
7(Note8)
(Note15)
LAN_ID1
R/W
0xA05
(Note2)
6
(Note9)
(Note15)
LAN_ID0
R/W
0xA00
(Note3)
6
(Note10)
(Note15)
PWR_ON
R/W
0xA00
(Note4)
4(Note11)
(Note15)
PWR_OFF
R/W
0xA00
(Note5)
2(Note12)
(Note15)
WDT_EN
R/W
0xA00
(Note6)
1
(Note13)
(Note15)
