N e t w o r k Ap p l i a n c e F W S - 7 8 1 0
Appendix C Standard LAN Bypass Platform Setting C-12
C.4 Software Reset button (General Propose Input)
Introduction
FWS-7810 provides a general propose input button which status can get by
AAEON SDK.
Soft Reset Button Configuration
Table 2 : LAN Bypass relative register table
Function Description
BTN_STS Reading this register returns the pin level status
which is normal high active low.
0: Pin Level States Low.
1: Pin Level States High.
Table 1 : Soft Reset Button register mapping table
Attribute Register(I/O) BitNum Value
BTN_STS R 0xA05
(Note1) 4(Note2) (Note3)
Sample Code
************************************************************************************
#define Word BTN_STS //This parameter is represented from Note1
#define Byte BTN_STS_R //This parameter is represented from Note2
************************************************************************************
Byte GET_Value (Word IoAddr, Byte BitNum,Byte Value) { BYTE TmpValue;
