AAEON FWS-7810 User Manual
Page 20
N e t w o r k Ap p l i a n c e
F W S - 7 8 1 0
Chapter 2 Quick Installation Guide
2-7
LAN1
10/100/1000 Base-TX Ethernet Connector
LAN2
10/100/1000 Base-TX Ethernet Connector
LAN3
10/100/1000 Base-TX Ethernet Connector
LAN4
10/100/1000 Base-TX Ethernet Connector
LAN5
10/100/1000 Base-TX Ethernet Connector
LAN6
10/100/1000 Base-TX Ethernet Connector
LAN7
10/100/1000 Base-TX Ethernet Connector
LAN8
10/100/1000 Base-TX Ethernet Connector
CPU_FAN1
4-Pin Fan Connector
SYS_FAN1
4-Pin Fan Connector
SYS_FAN2
4-Pin Fan Connector
CN7
SATA Power Connector
CN11~CN15
SATA Power Connector
CN4
Power Bottom
LCM1
LCM Connector
ATX1
24-Pin ATX Power Connector
ATX2
8-Pin ATX Power Connector
COM1/USB1
COM/USB3 Connector
SW1
Reset Switch (By Control)
