H a l f - s i z e S B C H S B - C V 1 P
Chapter 3 AMI BIOS Setup 3-34
1024x600,18bit,60Hz
1024x768,18bit,60Hz
1024x768,24bit,60Hz
1280x768,24bit,60Hz
1366x768,24bit,60Hz
Select LCD panel used by Internal Graphics Device by selecting the appropriate
setup item.
Active LFP No LVDS
LVDS Default
EDP
Select the Active LFP Configuration.
No LVDS:VBIOS does not enable LVDS.
Int-LVDS:VBIOS enables LVDS driver by Integrated encoder.
SDVO LVDS:VBIOS enables LVDS driver by SDVO encoder.
eDP Port-A:LFP Driven by Int-DisplayPort encoder from Port-A.
eDP Port-D:LFP Driven by Int-DisplayPort encoder from Port-D(through PCH).
LVDS Backlight Level 100%
90%
80% Default
70%
60%
50%
40%
30%
