M i n i - I T X E M B - A 5 0 M
Chapter 2 Quick Installation Guide 2 - 14
2.7 CMOS Setting (CLRTC) (JP1)
JP1 Function
1-2 Normal (Default)
2-3 Clear CMOS
2.8 CHASSIS INTRUDER (CHASSIS) (JP2)
JP2 Function
3-4 Normal
OPEN CHASSIS INTRUDER
2.9 Pin Header (USB 56, 78)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD1- 4 GND
5 USBD1+ 6 USBD2+
7 GND 8 USBD2-
9 GND 10 +5V
2.10 USB 3.0 Connector (USB 3_34)
Pin Signal Pin Signal
1 +5V_USB3_2_P1 11 +5V_USB3_2_P2
2 U3_2_U3RXDN1 12 U3_2_U3RXDN2
3 U3_2_U3RXDP1 13 U3_2_U3RXDP2
4 GND 14 GND
5 U3_2_U3TXDN1 15 U3_2_U3TXDN2
6 U3_2_U3TXDP1 16 U3_2_U3TXDP2
7 GND 17 GND
8 U3_2_U2DN1 18 U3_2_U2DN2
9 U3_2_U2DP1 19 U3_2_U2DP2
10 N.C 20 N.C
