I n d u s t r i a l M o t h e r b o a r d I M B A - Q 7 7
Appendix C Mating Connector C - 4
DIMM2
DDR3
204PIN
SKT KORTAK
AR240H-031
B-A0H
N/A
DIMM3
DDR3
204PIN
SKT KORTAK
AR240H-101
B-A0H
N/A
DIMM4
DDR3
204PIN
SKT KORTAK
AR240H-031
B-A0H
N/A
PCI1
PCI
Connector FOXCONN
EH06001-HH
W-DF N/A
PCI2
PCI
Connector FOXCONN
EH06001-HH
W-DF N/A
PCI3
PCI
Connector FOXCONN
EH06001-HH
W-DF N/A
KBMS1
Keyboard &
Mouse FOXCONN
MH11061-P3
6-4F N/A
DVI/COM1 COM1+DVI TechBast
D205D1B010
12PN N/A
DP1 DisplayPort FOXCONN 3VD21203-H
7U0-4H N/A
DP2 DisplayPort KORTAK 9S020F-03A
S-00H N/A
HDMI1 HDMI LOTES GSP-ABA-H
DM-013-K09
N/A
USB_LAN1
Dual USB &
LAN FOXCONN
JFM38U1B-2
1U5-4F N/A
USB_LAN2
Dual USB
3.0 & LAN UDE
05-000939M
23-1 N/A
AUDIO1
AUDIO
Connector FOXCONN
JA33331-211
9-4F N/A
