Signal – AAEON GENE-9455 Rev.А User Manual
Page 30
S u b C o m p a c t B o a r d
G E N E - 9 4 5 5
Chapter 2 Quick Installation Guide
2-18
2.23 USB Port 3, 4 Connector (CN9)
Pin Signal
Pin Signal
1
+5 Volt. Standby
2
Ground
3 Data2-
4 Ground
5 Data2+
6 Data3+
7 Ground
8 Data3-
9
Ground
10
+5 Volt. Standby
2.24 SATA 0 Connector (CN11)
Pin
Signal
1 Ground
2 TX0+
3 TX0-
4 Ground
5 RX0-
6 RX0+
7 Ground
2.25 SATA 2 Connector (CN12)
Pin
Signal
1 Ground
2 TX1+
3 TX1-
4 Ground
5 RX1-
6 RX1+
7 Ground
