S u b C o m p a c t B o a r d G E N E - 9 4 5 5
Chapter 2 Quick Installation Guide 2-15
107 PCI_AD2 108 +5 Volt. Standby
109 PCI_AD14 110 N/C
111 PCI_LOCK# 112 N/C
113 PCI_INT#B 114 N/C
115 PCI_AD12 116 N/C
117 PCI_AD10 118 N/C
119 PCI_AD8 120 N/C
121 PCI_AD7 122 N/C
123 PCI_INT#A 124 N/C
125 PCI_AD3 126 N/C
127 PCI_AD5 128 Ground
129 PCI_AD1 130 CLK48_IN
131 +3.3 Volt. 132 CLK33_IN
133 +3.3 Volt. 134 Ground
135 +3.3 Volt. 136 USB_D+
137 Ground 138 USB_D-
139 Ground 140 OC#
2.17 Keyboard/Mouse Connector (CN3)
Pin Signal Pin Signal
1 Keyboard Data 2 Keyboard Clock
3 Ground 4 +5 Volt.
5 Mouse Data 6 Mouse Clock
2.18 USB Port 1, 2 Connector (CN4)
Pin Signal Pin Signal
1 +5 Volt. Standby 5 +5 Volt. Standby
2 Data0- 6 Data1-
3 Data0+ 7 Data1+
