S u b C o m p a c t B o a r d G E N E - 9 4 5 5
1.3 Specifications
System

Processor Onboard Intel
®
Atom™ N270
Processor 1.6GHz, FSB
533MHz

System Memory 200-pin DDRII SODIMM x 1,
Max. 2GB (DDRII 400/533)

Chipset Intel
®
945GSE + ICH7M

I/O Chipset ITE8781

Ethernet Intel
®
82574L,
10/100/100Base-TX, RJ-45 x 2

BIOS Award Plug & Play SPI BIOS –
2MB Flash

Watchdog Timer Generates a time-out system
reset

H/W Monitor Chipset Supports power supply voltages
and temperature monitoring

Expansion Interface Mini PCI x 1 & ECX Proprietary
Expansion x 1
 Battery
Lithium battery

Power Requirement +8.5V to +24V Wide DC Input
Range or +5V only

Board Size 5.75”(L) x 4”(W) (146mm x
101.6mm)
Chapter 1 General Information 1- 4
