Appendix C Mating Connector
C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Connector
Label
Function
Mating Connector
Available
Cable
AAEON Cable
P/N
Vendor
Model no
CN1
LVDS
Connector
Hirose
1.25mm Pitch 30
Pins
DF13-30DS-1.25
C
N/A
N/A
CN2
SIM Card
Connector
Molex
Molex
51021-0800
N/A
N/A
CN3
SATA
Powerl
Connector
Molex
2.0mm Pitch 4
Pins (Molex
87369-040X)
SATA Power
Cable
1702150121
CN4
2P Power
Connector
N/A
N/A
Power Cable
1702002010 *
CN5
PCI/104
Connector
N/A
N/A
N/A
N/A
CN6
Fan
Connector
Molex
2.0mm Pitch 3
Pins Molex
87369-030X)
N/A
N/A
CN7
PS2
Keyboard/
Mouse
Connector
Molex
1.25mm Pitch 6
Pins (Molex
51021-0600)
Keyboard &
Mouse Cable
1700060155
CN8
Front
Panel
Connector
Molex
1.25mm Pitch 10
Pins
(Molex
51021-1000)
Front Panel
cable
1701010150
CN9
LAN LED
Connector
Molex
1.25mm Pitch 8
Pins (Molex
51021-0800)
LAN LED
Cable
1701080150
CN10
Mini Card
Connector
N/A
N/A
N/A
N/A
COM1
RS-232
Serial Port
Connector
Molex
1.25mm Pitch 9
Pins (Molex
51021-0900)
Serial port
Cable
1701090150
COM2
RS-232/
422/485
Serial Port
Molex
1.25mm Pitch 9
Pins (Molex
51021-0900)
Serial port
Cable
1701090150
