P C / 1 0 4 C P U M o d u l e P F M - L N P
1.3 Specifications
System
z
Processor Intel
®
Atom™N450 1.66 GHz
processor
z
System Memory Onboard DDRII 667,
Max. 1GB
z
Chipset Intel
®
N450+ICH8M
z
I/O Chipset SMSC3114
z
Ethernet Intel
®
82567V for
10/100/1000Base-TX
z
BIOS AMI BIOS – 4MB ROM
z
Wake on LAN Yes
z
Watchdog Timer Generates a time-out system
reset
z
H/W Status Monitoring Supports Power Supply
Voltage, Fan Speed and
Temperature Monitoring
z
Expansion Interface PCI -104 & Mini-Card
z Power
Requirement 12V
z Battery
Lithium battery
z
Board Size 3.55” x 3.77” (90mm x 96mm)
z
Gross Weight 0.33 lb (0.15 Kg)
z Operating
Temperature 32ºF ~ 140ºF (0ºC ~ 60ºC)
Chapter 1 General Information 1- 4
