PCMCIA/CompactFlash ™ ATA to IDE Drives and Modules
8
PCM-3116 PC/104 PCMCIA and/or CompactFlash
(ATA) to IDE Modules
The PCM-3116 family of drives bring the covenience of PCMCIA and
CompactFlash cards to industrial computer systems. PC/104 is a
version of the standard PC bus designed specifically for the particular
challenges of using PC technology in industrial and embedded com-
puter systems. All PCM-3116 models conform to the standard PC/104
form factor.
Connections can be made in two ways - either through the PC/104
connector or through the IDE and power connectors.
Common Specifications
• Complies with PCMCIA v. 2.1 / JEIDA 4.1 and CompactFlash
standards
• ATA/CompactFlash to IDE interface
• 40-pin IDE connector
• 4-pin standard power connector
• Supports Type I/II/III ATA Flash, ATA HDD and CompactFlash
cards through 68-pin PCMCIA connector or 50-pin
CompactFlash connector
• 5 V, 70 mA power consumption (typical)
• 0° C to 70° C operating temperature range
• Standard PC/104 form factor
