User’s Manual
21
PC/104 Connector
Pin Connector J1 Connector J2
Number Row A Row B Row C Row D
0 — — GND GND
1 IOCK# GND SBHE# MEM16
2 SD7 RESETDRV LA23 IO16#
3 SD6 +5V LA22 IRQ10
4 SD5 IRQ9 LA21 IRQ11
5 SD4 -5V LA20 IRQ12
6 SD3 DRQ2 LA19 IRQ15
7 SD2 -12V LA18 IRQ14
8 SD1 OWS# LA17 DACK0#
9 SD0 +12V MEMR# DRQ0
10 IOCHRDY GND MEMW# DACK5#
11 AEN SMEMW# SD8 DRQ5
12 SA19 SMEMR# SD9 DACK6#
13 SA18 IOW# SD10 DRQ6
14 SA17 IOR# SD11 DACK7#
15 SA16 DACK3# SD12 DRQ7
16 SA15 DRQ3 SD13 +5V
17 SA14 DACK1# SD14 MASTER#
18 SA13 DRQ1 SD15 GND
19 SA12 REFRESH# — GND
20 SA11 ATCLK# — —
21 SA10 IRQ7 — —
22 SA9 IRQ6 — —
23 SA8 IRQ5 — —
24 SA7 IRQ4 — —
25 SA6 IRQ3 — —
26 SA5 DACK2# — —
27 SA4 T/C — —
28 SA3 BALE — —
29 SA2 +5V — —
30 SA1 OSC — —
31 SA0 GND — —
32 GND GND — —
