Appendix D Electrical Specifications for I/O Ports D-4
Table 4 : Digital Input relative register table
LDN Register BitNum Value Note
DIO‐8 Pin Status 0x06 (Note59) 0x8A (Note60) 0 (Note61) GPIO80
DIO‐9 Pin Status 0x06 (Note62) 0x8A (Note63) 1 (Note64) GPIO81
DIO‐10 Pin Status 0x06
(Note65)
0x8A
(Note66)
2
(Note67)
GPIO82
DIO‐11 Pin Status 0x06
(Note68)
0x8A
(Note69)
3
(Note70)
GPIO83
DIO‐12 Pin Status 0x06
(Note71)
0x8A
(Note72)
4
(Note73)
GPIO84
DIO‐13 Pin Status 0x06
(Note74)
0x8A
(Note75)
5
(Note76)
GPIO85
DIO‐14 Pin Status 0x06 (Note77) 0x8A (Note78) 6 (Note79) GPIO86
DIO‐15 Pin Status 0x06 (Note80) 0x8A (Note81) 7 (Note82) GPIO87
Table 5 : Digital Output relative register table
LDN Register BitNum Value Note
DIO‐8 Output Data 0x06
(Note83)
0x89
(Note84)
0
(Note85) (Note86)
GPIO80
DIO‐9 Output Data 0x06
(Note87)
0x89
(Note88)
1
(Note89) (Note90)
GPIO81
DIO‐10 Output Data 0x06
(Note91)
0x89
(Note92)
2
(Note93) (Note94)
GPIO82
DIO‐11 Output Data 0x06
(Note95)
0x89
(Note96)
3
(Note97) (Note98)
GPIO83
DIO‐12 Output Data 0x06 (Note96) 0x89 (Note100) 4 (Note101) (Note102) GPIO84
DIO‐13 Output Data 0x06 (Note103) 0x89 (Note104) 5 (Note105) (Note106) GPIO85
DIO‐14 Output Data 0x06 (Note107) 0x89 (Note108) 6 (Note109) (Note110) GPIO86
DIO‐15 Output Data 0x06 (Note111) 0x89 (Note112) 7 (Note113) (Note114) GPIO87
