ITEM
NO. PART NAME PART
NUMBER MAT'L
CODE QTY ITEM
NO. PART NAME PART
NUMBER MAT'L
CODE QTY
SUPER T SERIES OM-05512
MAINTENANCE & REPAIR PAGE E - 7
PARTS LIST
T4A60S-(SAE 4/10) Pump End Assembly
1 PUMP CASING 10525D 10000 1
2 REPAIR ROTATING ASSY 44163-347 --- 1
3 PIPE PLUG P04 15079 1
4 DISCHARGE ELBOW R64 11990 1
5 PIPE NIPPLE T64 15070 1
6 HEX HD CAPSCREW B1007 15991 8
7 LOCKWASHER J10 15991 8
8 DISCHARGE FLANGE 1756 10010 1
9 FLANGE GASKET 25113-034 --- 1
10 BRG HOUSING O‐RING S1674 --- 1
11 HEX HD CAPSCREW B0806 15991 4
12 LOCKWASHER J08 15991 4
13 ROT ASSY ADJ SHIM 13130-3 17040 8
14 SEAL PLATE O‐RING 25152-273 --- 1
15 WEAR PLATE ASSY 10532A 15990 1
16 BACK COVER O‐RING 25152-273 --- 1
17 HEX NUT D06 15991 2
18 LOCKWASHER J06 15991 2
19 PIPE PLUG P20 10009 1
20 BACK COVER O‐RING S1674 --- 1
21 BACK COVER ASSY 42111-802 --- 1
22 -BACK COVER NOT AVAILABLE 1
23 -WARNING PLATE 2613EV 13990 1
24 -DRIVE SCREW BM#04-03 17000 4
25 -PRESS RELIEF VALVE 26662-005 --- 1
26 -WARNING DECAL 38816-302 --- 1
27 BACK COVER HANDLE 12354 13010 1
28 HEX HD CAPSCREW B0604 15991 2
29 LOCKWASHER J06 15991 2
30 HAND NUT 38115-202 15040 4
31 HEX HD CAPSCREW B0804-1/2 15991 4
32 LOCKWASHER J08 15991 4
33 LOCKING COLLAR 38115-551 15001 4
34 ADJUSTING SCREW 31871-070 1500X 4
35 STUD C1213 15991 4
36 SUCT FLANGE GASKET 11389G 19370 1
37 SUCTION FLANGE 11389 10010 1
38 HEX HD CAPSCREW B1008 15991 8
39 LOCKWASHER J10 15991 8
40 PIPE PLUG P04 15079 1
41 FLAP VALVE ASSY 46411-062 --- 1
42 PIN 11557 17010 1
43 PIPE PLUG P04 15079 1
44 CLAMP BAR 38111-004 11010 1
45 MACHINE BOLT A1014 15991 2
46 CLAMP BAR SCREW 31912-009 15000 1
47 FILL COVER ASSY 42111-344 --- 1
48 -FILL COVER NOT AVAILABLE 1
49 -WARNING PLATE 38816-097 13990 1
50 -DRIVE SCREW BM#04-03 17000 2
51 -FILL COVER GASKET 50G 19210 1
52 PIPE PLUG P08 15079 1
NOT SHOWN:
NAME PLATE 38818-040 13990 1
DRIVE SCREW BM#04-03 17000 4
LUBE DECAL 38817-084 --- 1
INSTRUCTION LABEL 2613DK --- 1
ROTATION DECAL 2613M --- 1
WARNING DECAL 2613FE --- 1
SUCTION STICKER 6588AG --- 1
PRIMING STICKER 6588AH --- 1
DISCHARGE STICKER 6588BJ --- 1
“SUPER T” DECAL 38812-089 --- 1
4” STRAINER 2690C 24000 1
INSTRUCTION TAG 38817-023 --- 1
DRIVE ASSY 44162-161 --- 1
G‐R DECAL GR-03 --- 1
OPTIONAL:
ALLOY STEEL WEAR 46451-729 24160 1
PLATE ASSY
DISASSEMBLY TOOL
12859 24000 1
SEWAGE SLUDGE
PRESS RELIEF VALVE
46431-628 --- 1
CLEANOUT KIT 48783-009 --- 1
AIR RELEASE VALVES:
‐10# COMP SPRING GRP33-07A --- 1
‐25# COMP SPRING GRP33-07 --- 1
‐80# COMP SPRING GRP33-07B --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
