SUPER T SERIES OM-05512
MAINTENANCE & REPAIR PAGE E - 5
PARTS LIST
46143-002 Deutz F3L Power Unit Kit
ITEM
NO.
PART NAME
PART
NUMBER MAT'L
CODE
QTY
1 DEUTZ F3L ENGINE 29217-021 --- 1
2 BASE/FUEL TANK 41553-005 24150 1
3 MUFFLER GUARD ASSY 42331-029 --- 1
4 WARNING DECAL 38816-169 --- 1
5 HEX HD CAPSCREW B1017 15991 2
6 LOCKWASHER J10 15991 2
7 HEX NUT D10 15991 2
8 BATTERY BOX KIT 42432-002 --- 1
9 OIL DRAIN ASSY 46342-033 --- 1
10 POS BATTERY CABLE 47311-118 --- 1
11 HEX HD CAPSCREW B1007 15991 4
12 HEX NUT D10 15991 4
13 LOCKWASHER J10 15991 4
14 FLAT WASHER K10 15991 8
15 FUEL GAUGE 29332-135 --- 1
16 FUEL PICKUP 29332-145 --- 2
17 HOSE ASSY 46341-796 --- 1
18 MALE CONNECTOR S1447 --- 1
19 R.H. ENGINE SIDE RAIL 34451-085 15080 1
20 L.H. ENGINE SIDE RAIL 34451-086 15080 1
21 HEX HD CAPSCREW B1006 15991 6
22 HEX NUT D10 15991 6
23 LOCKWASHER J10 15991 6
24 CONTROL PANEL KIT 48313-775 --- 1
25 FUEL LINE 11308A --- 1
26 HOSE CLAMP 26518-641 --- 2
27 HOSE BARB FITTING 26523-386 --- 1
28 EXHAUST ELBOW 31912-023 15990 1
29 WEATHER CAP S1331 --- 1
30 LIFTING BAIL KIT 48274-801 --- 1
NOT SHOWN:
FLOAT SWITCH 48312-980 --- 1
ENGINE STARTUP TAG 38816-269 --- 1
INDICATES PARTS RECOMMENDED FOR STOCK
