OM-01228 UNIT SERIES
PAGE B - 2 INSTALLATION
Gorman‐Rupp distributor or the factory to deter­
mine the repair or updating policy. Do not put the
pump into service until appropriate action has
been taken.
UNIT INSTALLATION
Lifting
Pump unit weights will vary depending on the
mounting and drive provided. Check the shipping
tag on the unit packaging for the actual weight, and
use lifting equipment with appropriate capacity.
Drain the pump and remove all customer‐installed
equipment such as suction and discharge hoses
or piping before attempting to lift existing, installed
units.
Use lifting and moving equipment in
good repair and with adequate capacity
to prevent injuries to personnel or dam­
age to equipment.
Mounting
Locate the pump in an accessible place as close as
practical to the liquid being pumped. Level mount­
ing is essential for proper operation.
The pump may have to be supported or shimmed
to provide for level operation or to eliminate vibra­
tion.
Specifications
See Table 1 for typical pump specifications.
Table 1. Pump Specifications
Pump
Model Voltage Phase Horse­
power
Motor
RPM
Cycle Suction
Coupler
Discharge
Coupler
02D3 115/230 1 1 3450 60 Hz 1-1/2” 1-1/2”
See Table 1 for typical pump specifications.
Table 2. Unit Specifications
Power
Cable Reel
Assembly
Suction
Hose
Ground
Wire
Standpipe Length
(Min) - (Max)
50 Ft.
(15,2 M.)
1-1/2” x 15 Ft.
38,1 MM x 4,6 M
10 Ft.
(3,1 M.)
42 Ft.
(12,8 M.)
Discharge
Hose
1-1/2” x 15 Ft.
38,1 MM x 4,6 M
7.25 Ft. - 12 Ft.
2,2 M - 3,7 M
Product Compatibility
The cleanout hose in the hose and reel assembly is
“Ambassador Hardwall 559N” hose manufactured
by Goodyear Tire and Rubber Company. It is com­
patible with most hydrocarbon products. Consult
the Goodyear Tire and Rubber Company or
www.goodyear.com for specific product compati­
bility.
Positioning Unit and Setup
Figure 2 shows a typical installation of the Tank­
leenor
R
system.
