UL Listed Natural Gas Boosters
Low Capacity Series
Dimensions: Shown in inches
Notes:
1. No special equipment foundation is necessary, but a level concrete
floor or block is recommended. Simply rest machine on cork pads
furnished; do not use anchor bolts. Flexible piping connections
are recommended.
2. Outlet position must be specified when the gas booster is ordered.
3. All dimensions are for reference only unless certified.
4. All units have thermal overload protection in motor and must be
connected according to NEC and local codes.
GL-O231-1/2-R 19 15 /
16
4 5 /
8
8 1 /
16
GL-O244-1/2-R 20 1 /
16
4 3 /
4
7 9 /
16
GL-O325-1/2-R 19 15 /
16
4 5 /
8
8 1 /
16
A
C
23 1 /
4
11 3 /
4
16
22 1 /
8
16 5 /
16
18 9 /
16
1 5 /
8
*
*1 3 /
4
on GL-0244- 1 /
2
-R
14 1 /
4
TDS-513B Copyright ©2009 The Spencer Turbine Company 0809KBA1.75
The Turbine Company, 600 Day Hill Road, Windsor, CT 06095-4706
Blowers & Vacuum Systems with an Engineering Edge
TEL 800-232-4321 ◆ 860-688-8361 ◆ FAX 860-688-0098 ◆ www.spencerturbine.com
º
Outlet Position:
Available outlet position as viewed from the outlet end of
the machine. Specify position on order.
Impeller
Explosion-
Proof Motor
Rotation
Inspection
Port
Axial Inlet
Electrical
Connector
Lifting
Lug
Cork Isolation Pads
1" (25 mm) thick
Gas Booster
Casing Outlet
(Position 1) Head
Gasket
Catalog
Number
Date: ________________________________________
Signed: _______________________________________
Customer Name: _______________________________
Customer Order No.: ____________________________
Project Name: _________________________________
Sales Order No.: ________________________________
B
A B C
For Customer Approval Certified Correct
Spencer may make improvements and dimensional changes to
equipment designs based on market trends and requirements.
For product selection assistance, please email
[email protected] or visit our website at
www.spencerturbine.com to locate the Spencer
representative in your area.
