MVX VGA A Matrix Switchers • Remote Contr
ol
4-3
Refer also to the
MVX VGA A User’
s Manual
at
www
.extron.com
.
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional description
Create ties
N • Commands can be entered back-to-back in a string, with no spaces. For example: 1*1!02*02&003*003%4*8$.
• The matrix switchers support 1-, 2-, and 3-digit numeric entries (1*1!, 02*02&, or 003*003%).
N When you create a tie where X! = 00, you tie no input to the specified output ( X@ ) (untie X@ ).
N The & tie command for RGB and the % tie command for video can be used interchangeably.
N The & read tie command for RGB and the % read tie command for video can be used interchangeably.
Tie input X! to output X@ , video
and audio
X! * X@ ! Out X@ • In X! • All ] Tie input X! ‘s video and audio to output X@ .
Example: 1*3! Out03•In01•All ] Tie input 1 video and audio to output 3.
Tie input X! to output X@ , RGBHV X! * X@ & Out X@ • In X! • RGB ] Tie RGB only (video breakaway).
Example
(see 3rd Note, above): 10*4& Out04•In10•RGB ] Tie input 10 RGB to output 4.
Tie input X! to output X@ , video X! * X@ % Out X@ • In X! • Vid ] Tie video only (video breakaway).
Example
(see 3rd Note, above) 7*5% Out05•In07•Vid ] Tie input 7 video to output 5.
Tie input X! to output X@ , audio X! * X@ $ Out X@ • In X! • Aud ] Tie audio only (audio breakaway).
Example: 12*04$ Out04•In12•Aud ] Tie input 12 audio to output 4.
Read RGB output tie X@ & X!] RGBHV input X! is tied to output X@ .
Read video output tie X@ % X!] Video input X! is tied to output X@ .
Read audio output tie X@ $ X!] Audio input X! is tied to output X@ .
N
X!
= Input number 00 – (maximum number of inputs for your model) (00 = untie)
X@ = Output number 01 – (maximum number of outputs for your model)
