Setup Guide — MDA 5V, 5SV, 5A RCA, cont’d
5
75 Ohm
HIGH
Z
LOOP
IN
2
4
1
3
12V
POWER
.1A MAX
MDA 5S
V
INPUT
OUTPUTS
Local Monitor
Flat Panel
Display
Flat Panel
Display
VCR
Extron
MDA 5SV
Distribution
Amplifier
Step 5 (optional)
For the MDA 5V:
Connect the video loop feed (
d
) to a local monitor, using composite video connectors.
For the MDA 5SV:
Connect a video loop feed (
d
) to a local monitor, using S-video connectors.
Step 6
For the MDA 5V and MDA 5SV models:
If a terminated device was connected to the loop feed in step 5, set the High Z/75 Ohm switch (
f
) to High Z (up
position, as shown in the figure at right). If no device or an unterminated device was connected to the loop feed
in step 5, set the switch to 75 Ohm (down position).
Step 7
For the MDA 5V:
Connect up to five display composite video devices to the outputs (
g
), using composite video connectors.
For the MDA 5SV:
Connect up to five display S-video devices to the outputs (
g
), using S-video connectors.
For the MDA 5A RCA:
Connect up to five stereo audio devices to the audio outputs (
h
), using the RCA connectors (left channel top; right channel
bottom).
Troubleshooting
If you have problems, please consult the full manual, which is available on-line at
.
If the problems persist, contact the
.
MDA 5A RC
A
POWE
R
12V
.3A MA
X
INP
UT
OUTPUTS
R
L
3
2
1
4
5
CD Player
Tape Recorder
Extron
MDA 5A RCA
Distribution
Amplifier
Extron
XPA 1002
Power
Amplifier
Extron
XPA 1002
Power
Amplifier
Extron
SI 28
Surface-mount
Speakers
Extron
SI 28
Surface-mount
Speakers
XP
A 1
002
1
2
LIM
ITER/PROTEC
T
SIGN
AL
OV
ER
TE
MP
XP
A 1
002
1
2
LIM
ITE
R/P
RO
TE
CT
SIGN
AL
OV
ER
TE
MP
HIGH Z
75 Ohm
