Receiver Connections
.
Front
Rear
L
R
OUTPUTS
DVI-D
AUDIO
DTP DVI 301 Rx
Rea
R
r
FFro t
nt
Rx
Tx
RS-232
IR
Rx
Tx
POWER
12V
0.7 A MAX
IN
ANALOG AUDIO
SIG LINK
DTP IN
10
9
11
8
7
Figure 3.
DTP DVI 301 Rx Connectors
g
DTP and Analog Audio Input RJ-45 connectors — Connect one end of the one
or two separate TP cables from the transmitter output connectors to these RJ-45 female
connectors.
CAUTION: Do not connect this device to a computer data or telecommunications
network.
NOTE: See “
“ to properly wire the RJ-45 connectors and for
detailed NOTES.
å
DTP Input connector (Required) — Ensure the free end of this cable is
connected to the transmitter DTP Out connector (
). This cable carries:
•
TMDS (digital) video
•
Embedded audio
•
Bidirectional RS-232 and IR commands and data
•
Remote power
Signal LED — This LED lights when the unit is receiving a TMDS clock signal on
the DVI input (transmitter) or any valid signal on the DTP In connector (receiver).
Link LED — This LED lights when a valid link is established between the units on
the DTP input and output cable.
ç
Analog Audio Input connector (Optional) — If desired, ensure the free end
of this cable is connected to the transmitter Analog Audio Out connector (
This cable carries analog audio only and is not needed for applications that do not
require this audio signal.
h
DVI-D output connector — Connect a display with a DVI input to display the
transmitted direct digital image. See “
“ for pin
assignments.
