Station ID and Sensor Offsets
Each field station has a unique Station ID number. This number is shown on the
configuration report provided with the system, and on a label placed at the top of the
controller board. The databases identify the sensor data for each of the input
channels using this station ID along with a sensor offset number. The offset is
added to the station ID to calculate the unique sensor number. These sensor
numbers are used to identify each of the input channels for any particular station.
The offsets are as follows:
Offset Channel Type
+0 Digital Control Output Register
+1 Analog Input Channel #1
+2 Analog Input Channel #2
+3 Analog Input Channel #3
+4 Analog Input Channel #4
+5 Analog Input Channel #5
+6 Analog Input Channel #6
+7 Analog Input Channel #7
+8 Analog Input Channel #8
+9 Battery Voltage Monitor
+10 Digital Status Input Register
+11 Digital Accumulator Input Channel #1
+12 Digital Accumulator Input Channel #2
+13 Digital Accumulator Input Channel #3
+14 Digital Accumulator Input Channel #4
For Example: For a SIT65 with a Station ID# of 14200, the Sensor ID# for analog
channel one is 14201, analog channel two is 14202, battery monitor is 14209, digital
input accumulator for channel one is 14211, etc.
