Oxi 3210 Operation
17 ba75795e02 03/2009
4.2.2 Navigation
Measured value display In the measured value display, you can
z Open the menu for calibration and measurement settings with
(short keystroke)
z Open the Storage & config menu with the sensor-independent
settings with
_
> (long keystroke (approx. 2 s).
z Change the display in the measurement window by pressing
(e.g. D.O. concentration
−> D.O. saturation index −> D.O. partial
pressure
−>).
Menus and dialogs The menus for settings and dialogs in procedures contain further
submenus. The selection is made with the <
▲><▼> keys. The current
selection is displayed with a frame.
z Submenus
The name of the submenu is displayed at the upper edge of the
frame. Submenus are opened by confirming with .
Example:
z Settings
Settings are indicated by a colon. The current setting is displayed on
the right-hand side. The setting mode is opened with .
Subsequently, the setting can be changed with <
▲><▼> and
. Example:
General
Clock
Service information
Reset
System
22.09.2008
08:00
Back
Language: English
Illumination : On
Contrast : 48 %
Switchoff time : 30 min
General
22.09.2008
08:00
Back
