Xylem Wastewater (Technical Manual) - Manual (Page 19)

PAGE 19
Wastewater
Goulds Water Technology, Bell & Gossett,
Red Jacket Water Products, CentriPro
Standard Panel Selection Check List
PANEL SIZING
Pump Model Chosen: __________________
1. Phase: Single_____ Three_____
2. Amp draw of pump: ____________ (found on bulletin)
3. Simplex (“1” Pump) _____ Duplex (“2” Pumps in Pit) _____
4. Does pump have a seal fail circuit: yes or no
(see note)
( NOTE: If Question 4 is yes, add a seal fail option as noted.)
If Question 1. Single 3. Simplex use Chart A
If Question 1. Three 3. Simplex use Chart B
If Question 1. Single 3. Duplex use Chart C
If Question 1. Three 3. Duplex use Chart D
CHART A
Panel Part Number Amp/ Enclosure
Maximum HP
S10020N1 (non-modifiable) up to 20 Indoor
S10020
up to 20 Indoor/
Outdoor
S12127 21-27 Indoor/
Outdoor
S12836 28-36 Indoor/
Outdoor
S1GD2 (includes caps for
2 HP Indoor/
1GD,12GDS after 12/2005) Outdoor
S1GGC2 (includes caps for
2 HP Indoor/
1GD,12GDS before 12/2005) Outdoor
S1FGC2
2 HP Indoor/
(use with1GA/15GDS) Outdoor
S1FGC3
3 HP Indoor/
(use with1/2GA/15/20GDS) Outdoor
S1FGC5
5 HP Indoor/
(use with 2GA /20GDS) Outdoor
Add option H for seal fail circuit to all of the above except S10020N1. Except for GA/
GDS grinder pumps, seal fail and high temperature are included in panel.
CHART B
Panel Part Number Amp/
Enclosure
Maximum HP
S31625 1.6-2.5 Indoor/Outdoor
S32540 2.5-4.0 Indoor/Outdoor
S34063 4.0-6.3 Indoor/Outdoor
S36310 6.3-10 Indoor/Outdoor
S31016 10-16 Indoor/Outdoor
S31620 16-20 Indoor/Outdoor
S32025 20-25 Indoor/Outdoor
S32232 22-32 Indoor/Outdoor
Add option H for seal fail circuit to all of the above, unless using a GA/GDS pump, use
an “O” option.
CHART C
Panel Part Number Amp/ Enclosure
Maximum HP
D10020N1 up to 20 Indoor
D10020
up to 20 Indoor/
Outdoor
D12127 21-27 Indoor/
Outdoor
D12836 28-36 Indoor/
Outdoor
D1GD2 (includes caps for
2 HP Indoor/
1GD,12GDS after 12/2005) Outdoor
D1GGC2 (includes caps for
2 HP Indoor/
1GD,12GDS before 12/2005) Outdoor
D1FGC2
2 HP Indoor/
(use with 1GA / 15GDS) Outdoor
D1FGC3
3 HP Indoor/
(use with 1/2GA / 15/20GDS) Outdoor
D1FGC5
5 HP Indoor/
(use with 2GA / 20GDS) Outdoor
Add option J for seal fail circuit to all of the above except D10020N1. Do not add seal
fail for GA/GDS grinder pumps, seal fail and high temperature are included in panel.
CHART D
Panel Part Number Amp/
Enclosure
Maximum HP
D31625 1.6-2.5 Indoor/Outdoor
D32540 2.5-4.0 Indoor/Outdoor
D34063 4.0-6.3 Indoor/Outdoor
D36310 6.3-10 Indoor/Outdoor
D31016 10-16 Indoor/Outdoor
D31620 16-20 Indoor/Outdoor
D32025 20-25 Indoor/Outdoor
D32232 22-32 Indoor/Outdoor
Add option J for seal fail circuit to all of the above except for GA/GDS pumps, use an
Option “P”. For other panel options see catalog for adders. For adders not found in
the catalog, or more than three options a specification is needed for the Customer
Service Department to prepare a quotation. Use of the Custom panel selection sheet
is advised with more than three options.
NOTE: Not all models are listed. For more assistance,
contact customer service.
