3
22-06-2009
Function Requirements: Hardware / Firmware / Software :
Converter HW Ver.: 807000
Converter FW Ver.: 842009-001
Display HW Ver.:
807055
Display FW Ver.: 841013-012
Texts file Ver.: 841513-010
MJK Field Link Ver.: 840110-035
Function description :
• In the Converter menu of the MagFlux connected to the display, the day Flow data
logger must be started and initialised.
• The day Flow is the volume measured by the MagFlux flow meter in 1 day (day
difference)
• Minimum 2 (two) days (date shift) must past before any Day Flow values are stored.
• Day Flow logger is using the forward counter, it’s not possible to log the reverse or
Sum flow.
• The Day Flow value is presented in a csv-file with date and time stamp+ unit.
• If the flow totalizer is zero (no flow present during the day), no Day flow is logged for
the day.
• The Day Flow is written to the Display logger at midnight (date shift)
• In case of Mains power loss the present day, Day flow will not be logged in the
Display logger.
• If Bluetooth is used for connection the Display (requires Display PCB HW Ver.:
510251-005 incl. FW Ver.: 841014-009) for downloading the log, the log size is
recommended to 1680 lines. (Setup->display->Graphs->size) This insures a
reasonable transfer time between the Display log and a PC by use of Bluetooth
connection.
