Designations:
Black Vcc + (24VDC) Output 4-20mA
White GND
Blue RS
485A
Yellow RS 485 B
Red NC
Air pressure compensation tube
Screen
Cutted and stripped Factory delivery
.
Please note the following installation instructions:
1. Follow the installation and safety instructions contained in the Operation Instructions.
2. Install according to the manufacturer’s instructions and other valid standards and guidelines.
3. Do not operate the sensor outside the specified electrical, thermal and mechanical parameters.
4. Install the device only in media for which the wetted materials have sufficient durability.
Be aware about the environment on the installation site. Use necessary protection equipment and follow all safety
regulations.
