indicating the maximum value is ready to be pro-
grammed. The currently programmed maximum
motor speed value is shown on the 3-DIGIT LCD.

4 Enter the motor speed at the maximum VDC input

signal value. Press the FIELD button to select the
digit to program. The digit will blink when selected.

4 Press the DIGIT button to change the selected digit.

4 Repeat until all digits are programmed.

4 Press the mode button. The % SPEED icon will stop

blinking and the VDC icon will blink indicating the
maximum VDC value is ready to be programmed. The
currently programmed maximum value is shown on
the 3-DIGIT LCD.

4 Enter the maximum VDC input signal value. Note:

this value must be greater than the minimum VDC
input signal value. Press the FIELD button to select
the digit to program. The digit will blink when
selected.

4 Press the DIGIT button to change the selected digit.

4 Repeat until all digits are programmed.

4 Press the mode button. Programming is complete.

4 To exit the programming mode, press the

RUN/STANDBY button and the MODE button at the
same time. The PROGRAM arrow will disappear.

PROGRAM MODE 3

% speed at the maximum input

RUN

PROGRAM

STAND-BY

PRIME

MINIMUM

MAXIMUM

% SPEED

MODE

100

PROGRAM MODE 3

maximum input value
