KELLER AG für Druckmesstechnik DCX Operating Instructions
- 3 -
Installation
The data loggers are lowered into the sinking pipe
and fixed in position with an adapter ring (see acces-
sories). The respective adapter ring is screwed onto
the DCX and secured with the Seeger circlip ring
supplied (see accessories).
It should be noted that the cable length selected initially for the DCX-22 AA / SG / VG is a
fixed dimension and cannot be changed. The desired cable length should therefore be
specified when ordering.
DCX-22
VG
DCX-22
AA
DCX-22
SG
DCX-22
Seeger circlip
Adapter ring
Read-out units
Rope
C
a
b
le
w
it
h
i
n
te
g
ra
te
d
re
fe
re
n
c
e
t
u
b
e
Water surface
C
a
b
le
l
e
n
g
th
S
y
s
te
m
l
e
n
g
th
Reference-
line of sensor
