Appendix A
Specifications
H-3342
Specifications A-1
General
Input:
Shaft angle + Turn count
Encoder: Absolute, non-contact
(optical & magnetic)
Outputs: SDI-12 & 4-20mA
Display: 4-1/2 digits x .4 in characters
(±199.99 or ±19999.)
Resolution: 65,536 (16-bit) counts/rev
Accuracy: 1/4096 (.00024 rev)
M ax Turns: ±32,768 rev
M ax Rotation Speed: 20 rev/sec
Offset Adjust:
SDI-12 or front panel adjust
4-20mA Output
Type:
4-20mA, optically isolated
Loop Voltage: 8.0V min, 35V max, loop powered
Resolution: 4µA (12-bit DAC)
SDI-12 Output
Baud Rate:
1200
Protocol: SDI-12, 7-bit even parity, 1 stop bit
Output Voltage Levels:
M inimum high level: 3.5 volts
M aximum low level: 0.8 volts
M aximum cable length: 250 ft
Pow er Requirements
Voltage Input: 9.6 to 30.0 Volts DC
Current:
150µA typical (sleep mode)
40mA typical (making measurement)
Turn Count Battery (internal):
Type: CR-1/3N (3.3V, 160mAh, lithium)
Lifetime:
10 years
Environmental
Operating Temperature:
-40 to 60 / C
Storage Temperature: -40 to 70 / C
Humidity: 0 to 100%
M echanical
Bearing:
Precision bearings with external seal
and low temperature lubricant
Starting Torque: 0.15 oz A in typical
0.50 oz A in max over temperature
Standard threaded shaft:
5/16" dia x 1.75" long
24-threads per inch x 0.75"
Optional non-threaded shaft:
5/16" dia x 1.75" long with setscrew flat
Housing M aterial: Anodized aluminum
Size: 5.25 in. wide (housing)
7.0 in. wide (mount flange)
4 in. deep(not including shaft or connector)
4.25 in. high (not including adjust knob)
Connector
H-3342: Amphenol M S3102R14S-6P (6-pin male)
Cable:
Amphenol M S3106A14S-6S (6-pin female)
(One cable provided with the H-3342)
W arranty
The W
A TE R LO G H-3342 is warranted against defects ®
in materials and workmanship for one year from date of
shipment.
