ASI v2 Operations (PRELIMINARY)
Operational Mode, DIP Switch Selection Settings
For changes in DIP switch settings to be effective, the ASI must be RESET after new switch
settings are entered. A RESET is done by either depressing the RESET switch on the ASI
board for 5 seconds or by powering the ASI board off for at least 90 seconds.
Baud Rate & ASYNC/SYNC selection
Switch 1 Switch 2
Open 0 Open 0 ASYNC (LL or RS232) 300 Baud
Closed 1 Open 0 ASYNC (LL or RS232) 1200 Baud
Open 0 Closed 1 ASYNC (LL or RS232) 4800 Baud
Closed 1 Closed 1 SYNC SERIAL (LL SCLK & LL DATA Input only)
Incoming Message Format
Switch 3 Switch 4
Open 0 Open 0 ALERT binary format (16 bits ID, 16 bits Data)
Closed 1 Open 0 ALERT ASCII format (4 chars ID, 4 chars Data)
Open 0 Closed 1 Reserved - Do not use
Closed 1 Closed 1 Diagnostic Mode if S1 & S2 are 1(see Diagnostic Mode DIP switch settings),
otherwise Reserved – Do not use.
ALERT Transmission Preamble Length (½ clear carrier, ½ mark tone)
Switch 5 Switch 6 Switch 7
Open 0 Open 0 Open 0 101 milliseconds
Closed 1 Open 0 Open 0 182
Open 0 Closed 1 Open 0 262
Closed 1 Closed 1 Open 0 343
Open 0 Open 0 Closed 1 424
Closed 1 Open 0 Closed 1 504
Open 0 Closed 1 Closed 1 585
Closed 1 Closed 1 Closed 1 665
ASYNC Input Voltage level Selection
(Note – this switch has no effect if SYNC serial is enable with Switch 1 & Switch 2)
Switch 8
Open 0 Logic Level input selected (0 V = 0, 3 to 5 V = 1)
Closed 1 RS232 (EIA) levels
