10
English
Base view
# Icon Item Description
1 Hard disk bay Houses the computer's hard disk
(secured with screws).
Memory compartment Houses the computer's main memory.
2 Battery lock Locks the battery in position.
3 Ventilation slots and
cooling fan Enable the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the
opening of the fan.
4 Battery bay Houses the computer's battery pack.
5 Battery release latch Releases the battery for removal.
1
2
3
4
5
