15
English
Base view
# Item Description
1 Battery bay Houses the computer’s battery pack.
2 Battery lock
latch Locks the battery in place.
3 Memory
compartment Houses the computer’s main memory (secured with
screws).
4 Cooling fan Cools computer during use.
Note: Do not cover or obstruct the opening of the fan.
5 Hard disk bay Houses the computer’s hard disk (secured with screws).
6 Optical drive Internal optical drive (hot-swappable Acer MediaBay
drive module is optional).
7 Optical drive
release latch Releases the optical drive module for removal.
8 Battery release
latch Releases the battery for removal.
