Page 14
Setting Up the Display
12
Connecting the Digital Input
1. Connect the VIDEO IN (DVI-D) jack on the display to the DVI-D output jack on a
computer using a DVI-D cable.
If the computer has an HDMI output jack
, connect the
computer’s HDMI output jack to the VIDEO IN (HDMI) input jack on the display
using an HDMI cable or a DVI-D to HDMI conversion cable.
2. Connect the computer’s audio output jack to the AUDIO IN (AUDIO1) jack on the
display using a suitable audio cable.
3. To view video image from this input, press the
DVI
or
HDMI
button on the remote
control.
Audio cable
Computer
*The cables are not supplied and should be purchased separately.
DVI-D cable
DVI-D to
HDMI
conversion
cable
HDMI
cable
Note:
Connector locations on the control panel may differ depending on the model.
