Setting Up the Display 10
Notes:
• To maintain proper ventilation, keep at least 100
mm of clear space around the display.
• Please consult a professional technician for wall
mount installations. The manufacturer accepts no
liability for installations not performed by a
professional technician.
Installing the Optional Desktop Stands
5. Install the wall mounting bracket
on the display and attach the
display to the wall according to
the mounting bracket’s
instructions. The length of the
screw should exceed the
thickness of the wall mounting
bracket by at least 10 mm. Make
sure that all screws are tightened
and secured properly.
(Recommended torque: 470 -
635N•cm). The mounting means
should be strong enough to bear
the weight of the display (about
28 kg without the stands).
1. Place a clean, dry and lint-free cloth on a flat, horizontal and object-free surface.
Make sure that the size of the cloth is larger than the display.
2. Place the desktop stands on the display
as illustrated.
3. Use the screws and a suitable
screwdriver to secure the stands on the
display.
Thickness of the
wall mounting
bracket
10 mm
(0.39”)
LCD display
100mm
(3.94”)
