Closed front view, Rear view – Acer Aspire 5534 User Manual
Page 7
7
Eng
lis
h
Closed front view
1. The front panel indicators are visible even when the computer cover is closed
up.
Rear view
#
Icon
Item
Description
1
Battery
1
Indicates the computer's battery status.
1. Charging: The light shows amber
when the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
2
Multi-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
(MS), Memory Stick PRO (MS PRO), xD-
Picture Card (xD).
Note: Push to remove/install the card.
Only one card can operate at any given
time.
#
Icon
Item
Description
1
Battery bay
Houses the computer's battery
pack.
