8
English
Closed front view
# Icon Item Description
1 3G switch/indicator Enables/disables the 3G function. Indicates
the status of 3G communication (only for
certain models).
2 Bluetooth
communication
switch/indicator Enables/disables the Bluetooth function.
Indicates the status of Bluetooth
communication.
3 Wireless
communication
switch/indicator Enables/disables the wireless function.
Indicates the status of wireless LAN
communication.
4 5-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
(MS), Memory Stick Pro (MS PRO), and xD-
Picture Card.
Note: Push to remove/install the card. Only
one card can operate at any given time.
5 Latch Locks and releases the lid.
6 Microphone jack Accepts inputs from external microphones.
7
.
Headphones/
speaker/line-out
jack. Connects to audio line-out devices
(e.g., speakers, headphones).
8
Infrared port
Interfaces with infrared devices
(e.g.,infrared printer and IR-aware
computer).
