Acer H7532BD User Manual
Page 52
42
En
gl
ish
3
HDMI - Video Signal
4
HDMI - 1.4a 3D Timing
Modes
Resolution
V.Frequency [Hz]
H.Frequency [KHz]
480i 720x480(1440x480)
59.94(29.97)
15.7
480p 720x480
59.94
31.5
576i
720x576(1440x576)
50(25)
15.6
576p
720x576
50
31.3
720p 1280x720
60
45.0
720p
1280x720
50
37.5
1080i 1920x1080
60(30)
33.8
1080i
1920x1080
50(25)
28.1
1080p
1920x1080
23.97/24
27
1080p
1920x1080
60
67.5
1080p
1920x1080
50
56.3
Modes
Resolution
V.Frequency
[Hz]
H.Frequency
[KHz]
720p (Frame Packing)
1280x720
50
37.5
720p (Frame Packing)
1280x720
60
45.0
1080p (Frame Packing)
1920x1080
24
27.0
720p (Top and Bottom)
1280x720
50
37.5
720p (Top and Bottom)
1280x720
60
45.0
1080i (Top and Bottom)
1920x1080
50 (25)
28.1
1080i (Top and Bottom)
1920x1080
60 (30)
33.8
1080p (Top and Bottom)
1920x1080
24
27.0
1080p (Top and Bottom)
1920x1080
50
56.3
1080p (Top and Bottom)
1920x1080
60
67.5
720p (Side by Side (Half))
1280x720
60
45.0
1080i (Side by Side (Half))
1920x1080
50 (25)
28.1
1080i (Side by Side (Half))
1920x1080
60 (30)
33.8
1080p (Side by Side (Half))
1920x1080
50
56.3
1080p (Side by Side (Half))
1920x1080
60
67.5
Graphic source monitor
range limits
Horizontal scan rate:
15k-100 kHz
Vertical scan rate:
24-120 Hz
Max. pixel rate:
Analog:165 MHz
Digital:165 MHz
