Acer Aspire 1690 - Manual (Page 18)

8
English
Bottom view
# Item Description
1 Hard disk bay Houses the computer's hard disk
(secured by a screw).
2 Battery release latch Unlatches the battery to remove the
battery pack.
3 Battery bay Houses the computer's battery pack.
4 Battery lock Locks the battery in place.
5 Cooling fan Helps keep the computer cool.
Note: Do not cover or obstruct the
opening of the fan.
6 Memory compartment Houses the computer's main memory and
Mini PCI Card.
