Acer Aspire 7560G - Manual (Page 10)

10
English
Base view
1
2
5 4
3
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery release latch/lock Releases the battery for removal.
Insert a suitable tool into the latch and slide
to release.
3 Memory compartment Houses the computer's main memory.
4 Hard disk bay-Main Houses the computer's hard disk (secured
with screws).
5 Hard disk bay-Secondary Houses the computer's hard disk (secured
with screws) (for certain models only).
Environment
• Temperature:
•
Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
•
Operating: 20% to 80%
• Non-operating: 20% to 80%
